Nocpix MICRO 2 ULTRA 1280 Thermal Monocular | 4 in 1 Thermal Optic

Nocpix MICRO 2 ULTRA 1280 Thermal Monocular

(2 week ship time)

The Nocpix MICRO 2 ULTRA represents a major advancement in compact thermal imaging technology. Built around an industry leading 1280 × 960 thermal sensor, this versatile 4 in 1 thermal optic combines the capabilities of a helmet mounted thermal monocular, thermal clip on, handheld scanner, and dedicated thermal weapon sight into one compact platform.

As the first 1280 resolution helmet mounted thermal monocular, the MICRO 2 ULTRA delivers exceptional image clarity, an ultra wide field of view, and impressive versatility for hunting, night vision integration, wildlife observation, and professional applications.

With a high resolution 2560 × 2560 AMOLED display, 60 Hz refresh rate, and advanced thermal processing, the MICRO 2 ULTRA provides detailed thermal imagery while maintaining smooth performance during movement.

Four Ways to Use One Thermal Optic

The MICRO 2 ULTRA is designed to adapt to your equipment and application without requiring multiple dedicated thermal devices.

Helmet Mounted Thermal Monocular

The ultra wide 34.2° horizontal field of view makes the MICRO 2 ULTRA an excellent option for helmet mounted thermal observation. Its wide viewing angle approaches the approximately 40° field of view of a traditional PVS 14, allowing users to observe more of their surroundings with less head movement.

Thermal Clip On

Convert a compatible daytime rifle optic into a thermal viewing system. The MICRO 2 ULTRA supports day optic magnifications from 1× to 10× and features three independent zeroing profiles for use across different rifle and optic configurations.

Handheld Thermal Scanner

Use the MICRO 2 ULTRA as a compact handheld thermal monocular for quickly scanning fields, wooded areas, property, and wildlife. Its high resolution sensor allows users to identify thermal details at greater digital magnification.

Dedicated Thermal Weapon Sight

With eight reticle options, adjustable reticle brightness, app based zeroing, and digital magnification up to 8×, the MICRO 2 ULTRA can function as a standalone thermal riflescope.

Industry Leading 1280 × 960 Thermal Resolution

At the heart of the MICRO 2 ULTRA is a 1280 × 960 Nocpix thermal sensor with 12 micron pixel technology and thermal sensitivity below 15 mK.

Compared to the 640 × 480 sensor found in the RH25 V2, the MICRO 2 ULTRA captures four times as many thermal pixels.

The upgraded 2560 × 2560 AMOLED display delivers nearly 4.7 times the display pixels of the RH25 V2, providing greater image detail and improved clarity when using digital magnification.

Combined with a 60 Hz refresh rate and advanced FastEngine processing, the MICRO 2 ULTRA provides smooth thermal imagery with reduced latency.

Ultra Wide Field of View

One of the most significant improvements of the MICRO 2 ULTRA is its exceptionally wide 34.2° × 25.9° field of view.

This provides substantially more viewing area than the 17.5° × 13.1° field of view commonly found on helmet mounted thermal optics.

The wider image is particularly beneficial for helmet mounted applications, thermal binocular configurations, and dual band systems combining thermal imaging with traditional night vision.

Advanced Night Vision Integration

The MICRO 2 ULTRA includes dedicated NV Highlight and NV Outline modes designed to improve compatibility with night vision systems.

These modes reduce unnecessary thermal background information, making it easier to distinguish heat signatures while allowing traditional night vision to provide surrounding environmental detail.

The Dual Link feature also allows two MICRO 2 ULTRA units to operate together as a thermal binocular system. A single master unit controls image settings, color palettes, zoom, and menus across both devices.

Improved Thermal Clip On Performance

The MICRO 2 ULTRA introduces several improvements for use with magnified daytime optics.

Its upgraded AMOLED display supports daytime optic magnification up to 10×, compared to the 6× support of the RH25 V2.

Three independent zeroing profiles allow users to save settings for different configurations, while the redesigned interface keeps important information visible as daytime optic magnification increases.

Additional Features

Picture in Picture: Maintain your full field of view while displaying a magnified window around the target and reticle.

FastEngine Processing: Advanced thermal processing architecture minimizes image latency for smoother observation.

Seamless Shutter: A 0.1 second shutter operation reduces interruptions and motion artifacts.

Wireless Remote: Included wireless remote provides convenient control of recording, brightness, menus, and digital magnification.

Advanced Power Management: True Sleep, Flip to Standby, and Power Saving Mode help conserve battery life. Power Saving Mode supports up to 6 hours of runtime.

Onboard Recording: Capture thermal video and images directly to the integrated 64GB storage.

Multiple Color Palettes: Choose from White Hot, Black Hot, Red Hot, Rainbow, Violet, Crimson, and Viridian.

Rugged Construction: Lightweight magnesium alloy housing with IP67 protection against dust and water.

Technical Specifications

Thermal Sensor and Display

Optical Specifications

Features and Electronics

Physical and Environmental Specifications

MICRO 2 ULTRA vs RH25 V2

The MICRO 2 ULTRA builds upon the proven RH25 V2 platform with significant improvements in thermal resolution, display quality, field of view, and clip on performance.

For users seeking greater thermal detail, a wider field of view, and improved integration with night vision equipment, the MICRO 2 ULTRA offers a substantial upgrade over previous generation compact thermal systems.

Built for Versatility

Whether you're building a helmet mounted thermal and night vision setup, upgrading your thermal clip on, or looking for a high resolution handheld thermal scanner, the iRay Nocpix MICRO 2 ULTRA delivers an exceptionally versatile thermal imaging platform.

With its 1280 resolution sensor, ultra wide field of view, rugged construction, and multiple mounting configurations, the MICRO 2 ULTRA brings advanced thermal imaging capabilities into a compact, lightweight package.
