Nocpix MICRO 2 H25 640 Thermal Monocular | 4 in 1 Thermal Optic

Nocpix MICRO 2 H25 640 Thermal Monocular

The Nocpix MICRO 2 H25 brings the next generation of compact thermal imaging to one of the most versatile thermal platforms available. Featuring an upgraded 640 × 512 thermal sensor, a high resolution 2560 × 2560 AMOLED display, and advanced FastEngine processing, the MICRO 2 H25 delivers exceptional thermal performance in a lightweight, compact design.

Built as a true 4 in 1 thermal optic, the MICRO 2 H25 functions as a helmet mounted thermal monocular, thermal clip on, handheld scanner, or dedicated thermal weapon sight. Whether you're hunting, scanning property, observing wildlife, or integrating thermal imaging into a night vision setup, the MICRO 2 H25 provides the flexibility to adapt to your application.

Compared to the previous RH25 V2, the MICRO 2 H25 introduces improved thermal sensitivity, reduced image latency, longer battery life, enhanced clip on compatibility, and a more compact housing.

Four Ways to Use One Thermal Optic

The MICRO 2 H25 is designed to provide multiple thermal imaging capabilities without requiring separate dedicated devices.

Helmet Mounted Thermal Monocular

The MICRO 2 H25 features a 17.5° × 13.1° field of view, making it well suited for helmet mounted thermal observation. Its compact magnesium alloy housing and lightweight 11.2 oz construction make it an excellent option for extended use alongside traditional night vision equipment.

Thermal Clip On

Transform a compatible daytime rifle optic into a thermal viewing system. The MICRO 2 H25 supports day optic magnification from 1× to 10×, an improvement over the 6× compatibility of the RH25 V2.

Three independent zeroing profiles allow users to save settings for multiple rifles or optic configurations.

Handheld Thermal Scanner

Use the MICRO 2 H25 as a handheld thermal monocular for scanning fields, wooded areas, property, and wildlife. Its 640 × 512 thermal sensor and 1,420 yard detection range provide the capability to locate heat signatures across a wide variety of environments.

Dedicated Thermal Weapon Sight

With eight reticle options, adjustable reticle brightness, app based zeroing, and up to 4× digital magnification, the MICRO 2 H25 can operate as a standalone thermal riflescope.

Upgraded 640 × 512 Thermal Sensor

At the heart of the MICRO 2 H25 is a second generation Nocpix 640 × 512 thermal sensor with 12 micron pixel technology and thermal sensitivity below 15 mK.

Compared to the RH25 V2, the upgraded sensor delivers approximately 20% greater responsivity, helping produce a cleaner thermal image with improved detail and contrast.

The high resolution 2560 × 2560 AMOLED display provides an exceptionally detailed viewing experience, allowing users to take advantage of the sensor's improved performance.

Combined with a 60 Hz refresh rate, the MICRO 2 H25 produces smooth thermal imagery during movement and scanning.

FastEngine Thermal Processing

The MICRO 2 H25 features Nocpix FastEngine processing technology, designed to improve thermal image responsiveness and reduce latency.

Compared to the previous generation, FastEngine reduces image latency by approximately 21%, providing a more responsive viewing experience.

This improvement is especially beneficial when scanning while moving or using the MICRO 2 H25 in helmet mounted configurations.

Improved Thermal Clip On Performance

The MICRO 2 H25 introduces several important improvements for use with daytime rifle optics.

Its upgraded 1.03 inch AMOLED display supports day optic magnification from 1× to 10×, compared to the 6× support of the RH25 V2.

The redesigned interface positions important information, including menus, battery status, and display indicators, closer to the center of the screen so they remain visible at higher magnification.

Three independent zeroing profiles allow users to save different configurations without having to repeat the entire zeroing process when switching setups.

The shorter housing also reduces the amount of rail space required for mounting.

Advanced Night Vision Integration

The MICRO 2 H25 is designed to integrate with traditional night vision equipment in dual band configurations.

Dedicated NV Highlight and NV Outline modes simplify the thermal image by reducing unnecessary background information.

NV Outline mode highlights the shape and location of heat signatures while allowing traditional night vision to provide the surrounding environmental image.

The Dual Link feature also allows two MICRO 2 H25 units to operate together as a thermal binocular system. A single master unit can control image settings, color palettes, zoom, and menus across both devices.

Compact and Lightweight Construction

The MICRO 2 H25 features a redesigned magnesium alloy housing measuring just 3.98 inches long and weighing approximately 11.2 ounces.

Compared to the RH25 V2, the shorter and narrower housing improves mounting flexibility, reduces occupied rail space, and provides additional clearance for helmet mounted binocular configurations.

Despite its compact size, the MICRO 2 H25 maintains IP67 water and dust resistance for dependable use in demanding outdoor environments.

Extended Battery Life and Power Management

The MICRO 2 H25 operates on a single rechargeable 18650 battery and supports external power through USB C.

Standard battery runtime is rated at more than 6.5 hours, while Auto Power Save can extend runtime to approximately 9 hours under supported conditions.

Additional power management features include True Sleep, Flip to Standby, and instant wake from standby.

These features help conserve battery power during periods of inactivity without sacrificing quick access to thermal imaging when needed.

Additional Features

Picture in Picture: Maintain the full field of view while displaying a magnified aiming window around the target and reticle.

Wireless Remote: Included wireless remote provides control over recording, brightness, menus, and digital magnification.

Enhanced Video Recording: Capture thermal footage at 1280 × 960 resolution, a significant improvement over the RH25 V2 recording resolution.

64GB Internal Storage: Store recorded thermal video and images directly on the device.

Multiple Color Palettes: Choose from White Hot, Black Hot, Red Hot, Rainbow, Violet, Crimson, and Viridian.

Advanced Zeroing: Three independent zeroing profiles, numerical zero values, and app based zeroing capabilities.

Fast Startup: Startup in under 10 seconds with instant wake from standby.

User Updatable Firmware: Keep the device updated with supported firmware improvements.

Rugged Construction: Magnesium alloy housing with IP67 protection against water and dust.

Technical Specifications

Thermal Sensor and Display

Optical Specifications

Features and Electronics

Physical and Environmental Specifications

MICRO 2 H25 vs RH25 V2

The MICRO 2 H25 builds upon the RH25 V2 with improvements in sensor performance, display resolution, battery life, and clip on compatibility.

The MICRO 2 H25 maintains the familiar field of view and versatility of the RH25 platform while introducing meaningful improvements to image quality, power management, and overall usability.

Built for Versatility

Whether you're building a helmet mounted thermal and night vision system, upgrading your thermal clip on, or looking for a compact handheld thermal scanner, the Nocpix MICRO 2 H25 delivers a versatile thermal imaging solution.

With its upgraded 640 × 512 sensor, high resolution AMOLED display, improved battery life, and compact construction, the MICRO 2 H25 brings next generation thermal imaging capabilities into one lightweight platform.
